ContactCOORDINAE MEASURING MACHINE (CMM)
With the help of this device used to determine the coordinates of the measured part, we use it to check the conformity of the parts we produce at the end of the manufacturing process to the dimensional and geometric tolerances in the specifications.
The CMM device can also be used for solid model, surface model and lattice model measurements used in reverse engineering applications.
CMM Device Application Areas?
HEXAGON GLOBAL S-GREEN 07-10-07
TECHNICIAL SPECIFICATIONS:
Net Measurement Volume
X : 700 mm
Y : 1000 mm
Z : 660 mm
HH-AS8-T5, Automatic indexable CNC Rotary Head
Structural Thermal Compensation
PC DMIS CAD ++ measurement software
The high-resolution METALLUR® scales can be controlled to respond to temperature changes of scattered scales with known elongation coefficients. Resolution: 0.039 μm.
ZOLLER SMILE400 TOOL MEASUREMENT DEVICE
Tool parts wear and change in size during part manufacturing. Failure to observe these changes causes the part to fall outside the tolerance range. Thanks to its ability to perform high-precision tool measurements, the Zoller tool gauge ensures the most efficient use of your tools.
